DCMT Carbide Inserts TiN Coated, 10 Pcs/Box
Regular price
From
$65.00 CAD
Unit price
/
Unavailable
DCMT Carbide Inserts TiN Coated, 10 Pcs/Box
DCMT inserts are 55° rhombic inserts with a 7° positive clearance for turning and finishing applications. When a cutting edge of the DCMT insert becomes dull, you just need to rotate the insert in the holder to use the sharp edge. The TiN coating of the inserts provides longer tool life than uncoated inserts.
- Carbide inserts
- C5 Grade Coated
- TiN Coated
- 10 pc/box
Table (mm)
| Item # | Product # | ANSI | I.S.O. # | d | L | S | d1 | r |
| 6104-1010 |
2104-1010 | DCMT21.51 | DCMT070204 | 6.35 | 7.8 | 2.38 | 2.8 | 0.4 |
| 6104-1014 |
2104-1014 | DCMT32.51 | DCMT11T304 | 9.525 | 11.6 | 3.97 | 4.4 | 0.4 |
Table (inch)
| Item # / Product # | Inset | ISO | I.C | Thickness | Hole | Radius |
| 6104-1010 / 2104-1010 | DCMT21.51 | DCMT070204 | 1/4" | 3/32" | 0.110" | 1/64" |
| 6104-1014 / 2104-1014 | DCMT32.51 | DCMT11T304 | 3/8" | 5/32" | 0.173" | 1/64" |
